300WP Standard Poly Crystalline Solar Panel For Sale With Good Quality

  • >=1 Watts
    $0.55
Material:
Polycrystalline Silicon
Max. Power:
300w
Number of Cells:
72
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
suoyang
Model Number:
SY-300P
Size:
1956*992*35
Original:
China manufacturer
Certificate:
CE,Rohs,TUV, ISO
weight:
22kg
quality:
A grade
Gurantee:
25years
Power:
300W solar panel
Color:
Blue
Junction Box:
TUV Certificate
Warranty:
25 Years Output Power Guarantee
Front Glass:
3.2mm Tempered
Supply Ability
Supply Ability:
1000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
1.Neutral packing, 2pcs in one carton, strengthen by pallets
2.31piece one wooden pallet. 20GP 340PCS,40FT 744PCS,40HQ 816PCS
(300WP Standard Poly Crystalline Solar Panel For Sale With Good Quality)
Port
Shenzhen
Video Description

300WP Stand Poly Crystalline Solar Panels For Sale



Productroduct Feature



1) High module conversion efficiency, through superior manufacturing technology.

2) Bypass diode minimizes the power drop by shade.

3) White tempered glass ,EVA resin,weather proof film and anodized aluminum frame to provide efficient protection from the severest environmental conditions.

4) Waterproof.Perfect for grid applications.

5) Solar panel guarantee 25 years performance.



Quality Assurance



 Electrical Insulation test

 Damp heat Test

 Outdoor exposure test

 Robustness of terminations test

 Hot-spot endurance test

 Wet leakage current test

 UV-exposure

 Mechanical load test

 Thermal cycling test

 Hail impact test

 Humidity freeze test

 Bypass diode thermal test



Electrical Characteristics

Type Of Panel

SY-300WP

Maximum Power (W)

300

Tolerance (%)

± 3%

Open Circuit Voltage (V)

38.0

Short Circuit Current (A)

7.89

Maximum Power Voltage (V)

45.4

Maximum Power Current (A)

8.4

Solar Cell Efficiency (%)

17.12

Series Fuse Rating (A)

15

Maximum system voltage (V)

DC1000

Operating Temperature(°C)

-40°C ---+85°C



Mechanical Characteristics

Solar Cell

Poly-crystalline silicon 156 × 156 mm (6 inches)

No. of Cells

72 (6 × 12)

Dimensions

1956 × 992 × 45mm

Weight

22.0 kgs

Front

3.2 mm tempered glass

Frame

Anodized aluminium alloy

Junction Box

 IP65

Output Cables

 90cm

Connectors

MC4



Temperature Characteristics

Nominal Operating Cell Temperature (NOCT)

45±2°C

Temperature Coefficient of Pmax

-0.47 %/°C

Temperature Coefficient of Voc

-0.34 %/°C

Temperature Coefficient of Isc

0.06 %/°C



Factory





Solar Panel Packing Detail





Certificate
