Poly PV Solar Panels 100WP Good Price

FOB Reference Price:Get Latest Price
US $0.35-0.5 / Watts | 1 Watt/Watts (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
suoyang
Model Number:
SY-100P
Material:
Polycrystalline Silicon
Size:
1005*670*35
Number of Cells:
36
Max. Power:
100W
performance:
pv solar panel good price
certificate:
CE,Rohs,TUV,ISO
weigt:
8kgs
SupplyAbility
SupplyAbility:
1000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Neutral packing, 2pcs in one carton, strengthen by pallets
Port
Shenzhen
Lead Time :
Shipped in 10 days after payment

Poly Crystalline Silicon Solar PV Panels 100WP

  • ITEM NO.: SY-100P
  • Cell Type: Poly-crystalline Silicon Solar cells
  • Maximum power (Wp): 100wp
  • Maximum power voltage (V): 18.40V
  • Maximum power current (A): 5.68A
  • Open circuit voltage (V): 22.0V
  • Short circuit current (A): 6.33A
  • Number of cells (Pcs): 36 (4*9) PCS
  • Size of module (mm): 1005 x 670 x 30mm (156*156mm cell)
  • Temperature Range: -40°C~+85°C
  • NOVT(Nominal Operating Cell Temperature): 45°C±2°C
  • Voltage temperature coefficient (VOC): -0.38%/°C
  • Current temperature coefficient(ISC): +0.1%/°C
  • Power temperature coefficient (Pmp): -0.47%/°C
  • Maximum system voltage (V): 1000V
  • Surface Maximum Load Capacity: 60m/s(200kg/sq.m)
  • Allowable Hail Load: steel ball dropped from 1 meter
  • Certificates: CE, ROHS, ISO
  • Output tolerance (%): ±3%
  • Weight per piece (kg): 8KG
  • Glass Type: 3.2mm Tempered Glass
  • Junction Box Type: Passed the TUV certified
  • Length of Cables (mm): 750mm
  • Connector Type: MC4
  • Frame (Material, Corners, etc.): Anodized Aluminum Alloy
  • Cell Efficiency (%): ≥16.8%
  • Module Efficiency (%): ≥14.80%
  • FF (%): ≥73%
  • Standard Test Conditions: AM1.5 100mW/cm2 25’C
  • Warranty: 12years for 90% power ,25years for 80% power;
  • Solar
