Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: suoyang
  • Model Number: SY-100M
  • Material: Monocrystalline Silicon
  • Size: 1210x540x35
  • Number of Cells: 36
  • Max. Power: 100W
  • Certificate: ISO,TUV,CE,RoHs
  • Weight: 9kgs
  • Warranty: 25 Years Output Power Guarantee
  • Frame: Anodized Aluminium Alloy
  • Type: 100w Monocrystalline Solar Panel
  • Junction Box: IP65 Rated

Packaging & Delivery

Packaging Details Neutral packing, 2pcs in one carton, strengthen by pallets
Delivery Time Shipped in 10 days after payment

  TUV Certified Solar Panels Manufacturers in China Mono 100WP

  • ITEM NO.: SY-100M
  • Cell Type: Mono-crystalline Silicon Solar cells
  • Maximum power (Wp): 100wp
  • Maximum power voltage (V): 18.50V
  • Maximum power current (A): 5.40A
  • Open circuit voltage (V): 22.50V
  • Short circuit current (A): 5.60A
  • Number of cells (Pcs): 36 (4*9) PCS
  • Size of module (mm): 1210x 540x 35mm (125*125mm cell)
  • Temperature Range: -40°C~+85°C
  • NOVT(Nominal Operating Cell Temperature): 45°C±2°C
  • Voltage temperature coefficient (VOC): -0.38%/°C
  • Current temperature coefficient(ISC): +0.1%/°C
  • Power temperature coefficient (Pmp): -0.47%/°C
  • Maximum system voltage (V): 1000V
  • Surface Maximum Load Capacity: 60m/s(200kg/sq.m)
  • Allowable Hail Load: steel ball dropped from 1 meter
  • Certificates: TUV, ROHS, CE, ISO
  • Output tolerance (%): ±3%
  • Weight per piece (kg): 9.0KG
  • Glass Type: 3.2mm Tempered Glass
  • Junction Box Type: Passed the TUV certified
  • Length of Cables (mm): 900mm
  • Connector Type: MC4
  • Frame (Material, Corners, etc.): Anodized Aluminum Alloy
  • Cell Efficiency (%): ≥18.7%
  • Module Efficiency (%): ≥15.3%
  • FF (%): ≥73%
  • Standard Test Conditions: AM1.5 100mW/cm2 25’C
  • Warranty: 12years for 90% power ,25years for 80% power;
