Power 185Wp 6 inch Poly Crystalline Silicon Solar Cell
- ITEM NO.: SY-185P
- Cell Type: Poly-crystalline Silicon Solar cells
- Maximum power (Wp): 185wp
- Maximum power voltage (V): 24V
- Maximum power current (A): 7.71A
- Open circuit voltage (V): 29.28V
- Short circuit current (A): 8.32A
- Number of cells (Pcs): 48 (6*8) PCS
- Size of module (mm): 1320 x 992 x 35mm (156*156mm cell)
- Temperature Range: -40°C~+85°C
- NOVT(Nominal Operating Cell Temperature): 45°C±2°C
- Voltage temperature coefficient (VOC): -0.38%/°C
- Current temperature coefficient(ISC): +0.1%/°C
- Power temperature coefficient (Pmp): -0.47%/°C
- Maximum system voltage (V): 1000V
- Surface Maximum Load Capacity: 60m/s(200kg/sq.m)
- Allowable Hail Load: steel ball dropped from 1 meter
- Certificates: TUV, ROHS, CE, ISO
- Output tolerance (%): ±3%
- Weight per piece (kg): 14.50KG
- Glass Type: 3.2mm Tempered Glass
- Junction Box Type: Passed the TUV certified
- Length of Cables (mm): 900mm
- Connector Type: MC4
- Frame (Material, Corners, etc.): Anodized Aluminum Alloy
- Cell Efficiency (%): ≥15.8%
- Module Efficiency (%): ≥14.16%
- FF (%): ≥73%
- Standard Test Conditions: AM1.5 100mW/cm2 25’C
- Warranty: 5 years product warranty, 10years for 90% power ,25years for 80% power;
- Solar
